Titanium Conductor Bar

Titanium conductor bars are used to distribute electrical current from the power source (usually an impressed current anode system) to the protected structure. They effectively carry the electrical current across different parts of the structure that require protection.

Product Name SKU Quote Preview
Product Downloads
Titanium Conductor Bar 1015

Product Inquiry

Product:
Model:

Titanium conductor bars are used to distribute electrical current from the power source (usually an impressed current anode system) to the protected structure. They effectively carry the electrical current across different parts of the structure that require protection.

KEY FEATURES

  • Durability and Longevity
  • High and Stable Current Output
  • Min. Maintenance and Reliability
  • High Efficiency
  • Various Applications

SPECIFICATIONS

  • Material:Titanium - ASTM B265 Grade 1
  • Dimension:12.7mm×0.9mm
  • Life Expectancy:50 years
  • Coil Length:100m
  • Coil Weight:5.5Kgs

Power Feeder Connector

A power feeder connector is crucial for ensuring effective electrical connection and current distribution in various systems, contributing to the overall reliability and efficiency of the electrical network.

  • Material:
  • A: Titanium Bar - ASTM B265 Grade 1
  • B: Titanium Rod - ASTM B348 Grade 1
  • Dimension: 12.7mm Width Ti bar, Length Customized; 3.0MM Width Rod, Length Customized
  • Welding Points: 6 Nos
  • Optional: Encapsulated with epoxy resin and connected with cable tail.

APPLICATIONS

  • Storage Tank Protection
  • Concrete Rebar Protection
  • Offshore Structure Protection
  • Long Pipeline Protection
Dimensions 12.7mm×0.9mm×100m/Coil
Weight 5.5kgs
Service life 50years
Substrate Titanium - ASTM B265 Grade 1 or Grade 2
