The Shunt is a precision resistor used for measuring large currents. Its core principle is to divert most of the current to be measured through itself, allowing only a small portion to flow through the measuring instrument, thereby indirectly and safely obtaining the value of the large current by measuring the small current.
SPECIFICATIONS
- Production Range: 1A-50A 10mV-800mV;51A-2500A 10mV-300mV
- Ambient Condition: -25°C to +80°C
- Relative Humidity: <80%
- Temperature Rise: Put in rated current for 2hr,after the temperature rising steady test it:When the rated current<100A,the temperature rise should be<80K;When the rated current>100A, the temperature rise should be ≤100K.
- Over Load Performance: 120% of rated current for 2hours. Thermoelectric Potential Influence: no more than 50% of theindex level
