Ex-Proof Junction Box

A cathodic protection explosion-proof junction box is a specialized type of junction box designed for use in environments where there is a risk of explosive atmospheres.

Product Name SKU Quote Preview
Product Downloads
Ex-Proof Junction Box 1038

Product Inquiry

Product:
Model:

A cathodic protection junction box is a crucial component in cathodic protection (CP) systems, used to manage and facilitate the distribution and monitoring of electrical currents in corrosion control applications. These junction boxes are designed to be versatile, accommodating various electrical characteristics while also being tailored to withstand specific environmental conditions.

Our cathodic protection junction boxes are designed to provide accurate and reliable connecting, effective management, monitoring, and control of CP systems, ensuring optimal performance in preventing metal.

A cathodic protection explosion-proof junction box is a specialized type of junction box designed for use in environments where there is a risk of explosive atmospheres.

KEY FEATURES

  • Safe and Reliable Components Optional
  • Customized Materials and Dimensions
  • Maintenance and Reliability
  • Easy Installation and Disassemble
  • Heavy Duty Steel Enclosure

SPECIFICATIONS

  • Enclosure Material: Casting Aluminum or Stainless Steel
  • Terminal: 2 to 20nos of Copper Terminals
  • Busbar: Copper 25mm x 5mm
  • Insulation Plate: Epoxy
  • Cable Entrance: Exd Cable Gland
  • Supporting: Back Galvanized Steel Bracket
  • Resistor: Adjustable Resistor 10~500W
  • Shunt: 1A~100A/75mV
  • Crimp Lugs: Included
  • Disconnecting Bar: Optional
  • Normal Explosion Grade: Exd IIB T4
  • IP Grade: IP66
  • Temperature: -40°C to +80°C
  • Application Area: Zone I or Zone II
Operating Temperature Range -40°C to +80°C
IP Grade IP66
Explosion Proof Exd IIB T4
Enclosure Material Casting Aluminum/Stainless Steel
Application Area Zone I or Zone II
